Shure
ULXD4D Dual Digital Wireless Receiver
$3,299.00
RF band
Qty
1
- Returns
- Warranty
- 30 days from delivery, in original condition and packaging.
- After the return window the manufacturer’s warranty applies. Spencer Clem does not add one of its own.
Overview
Two-channel digital wireless receiver with AES-256 encryption and Dante outputs.
Specifications
Power
Voltage
Power inlet
Physical
Width × height × depth
Rack units
Mounting
Finish
Network
Management
VLAN
RF
Documentation
Visualization
Default zone
Placement
Notes
Source
Not recorded. This section has not been filled in for this product.
Where the figures are uncertain
Tuning range depends on the band variant ordered, so no frequency range is recorded. XLR outputs are switchable mic or line level and are typed as line here.
Inputs and outputs
Grouped the way the back panel is grouped. Port labels are the manufacturer’s own, so they match what is silk-screened on the chassis.
Antenna in
| Port | Label | Connector | No. |
|---|---|---|---|
| In | Antenna A | BNC female | 1 |
| In | Antenna B | BNC female | 2 |
Antenna cascade
| Port | Label | Connector | No. |
|---|---|---|---|
| Out | Cascade A | BNC female | 1 |
| Out | Cascade B | BNC female | 2 |
Audio out
| Port | Label | Connector | No. |
|---|---|---|---|
| Out | Ch 1 Audio Out | XLR3 male | 1 |
| Out | Ch 2 Audio Out | XLR3 male | 2 |
| Out | Ch 1 1/4-inch Out | TRS 1/4" female | 3 |
| Out | Ch 2 1/4-inch Out | TRS 1/4" female | 4 |
Dante
| Port | Label | Connector | No. |
|---|---|---|---|
| Bidirectional | Dante Primary | RJ45 female | 1 |
| Bidirectional | Dante Secondary | RJ45 female | 2 |
Mains
| Port | Label | Connector | No. |
|---|---|---|---|
| In | AC Mains In | IEC C13/C14 male | 1 |
Passthrough
These outputs mirror an input rather than originating a signal, so a diagram follows the run straight through them.
- antenna_in 1 to antenna_cascade 1
- antenna_in 2 to antenna_cascade 2
