Allen & Heath

DX168 Stage Box

Model DX168

$1,349.00

SKU ALLEN-HEATH-DX168

Qty

Returns
Warranty: 30 days from delivery, in original condition and packaging.; After the return window the manufacturer’s warranty applies. Spencer Clem does not add one of its own.

Overview

16-input, 8-output remote stage box on a single Cat5e DX Link run.

dx · stage box · expander

Power

Voltage100-240 V AC

Power inletIEC C14

Physical

Width × height × depth483 × ? × ? mm

Rack units2U

MountingRack

FinishBlack

Network

ManagementControlled by the host console

VLANDX Link is point to point and must not share a switch with house traffic

DocumentationNot recorded

Visualization

Default zonestage

PlacementStage rack or a wall-mounted shelf near the inputs

Notes

SourceManufacturer published specifications.

Not recorded. This section has not been filled in for this product.

4 groups

Grouped the way the back panel is grouped. Port labels are the manufacturer’s own, so they match what is silk-screened on the chassis.

Mic/line in

Analog mic · 16 in / 0 out

Port	Label	Connector	No.
In	Mic/Line In 1	XLR3 female	1
In	Mic/Line In 2	XLR3 female	2
In	Mic/Line In 3	XLR3 female	3
In	Mic/Line In 4	XLR3 female	4
In	Mic/Line In 5	XLR3 female	5
In	Mic/Line In 6	XLR3 female	6
In	Mic/Line In 7	XLR3 female	7
In	Mic/Line In 8	XLR3 female	8
In	Mic/Line In 9	XLR3 female	9
In	Mic/Line In 10	XLR3 female	10
In	Mic/Line In 11	XLR3 female	11
In	Mic/Line In 12	XLR3 female	12
In	Mic/Line In 13	XLR3 female	13
In	Mic/Line In 14	XLR3 female	14
In	Mic/Line In 15	XLR3 female	15
In	Mic/Line In 16	XLR3 female	16

Line out

Analog line · 0 in / 8 out

Port	Label	Connector	No.
Out	Line Out 1	XLR3 male	1
Out	Line Out 2	XLR3 male	2
Out	Line Out 3	XLR3 male	3
Out	Line Out 4	XLR3 male	4
Out	Line Out 5	XLR3 male	5
Out	Line Out 6	XLR3 male	6
Out	Line Out 7	XLR3 male	7
Out	Line Out 8	XLR3 male	8
